Bio - Erector 1.0
An innovative modular Printer for pharmaceuticals/cosmetic testing, tissue engineering, regenerative medicine, bio-sensor and many more.
Compatible material: Bioinks (Collagen, Gelatin), PLGA, PDMS, Sugar etc.
Features
- Modular Print Head: You can just exchange the print head and make it an FDM printer or Bio-printer.
- Auto-Bed Levelling
- Close/Clean Chamber
- Temp-controlled Printhead & Print bed. Print Head Temperature: 24 – 60°C, Print Bed Temperature: 24 – 120°C
- UV Curing: Wavelength 365& 405nm for curing
- Quality-Cost efficiency Balance
Specifications
- Stepper Motors Resolution= 12.5 micron
- Layer Resolution= 100 micron
- Nozzle(Needle) Diameter= Up to 26 Gauge
- Working Dimensions= 200x200x100 mm3
- Printheads=1
- Photocuring sources= 405 (365 Optional) nm
- UV-Sterilization= yes with 275nm
- Bed Temperature= 120 °C (Max)
- Product Dimension= 530x500x571 mm3
